Medium Duty Panel Formwork in Imperial Sizes MEGALITE

Lightweight, medium duty handset panel formwork in imperial measurements for concrete walls, columns and pilasters in building construction and civil engineering projects.

Gallery

MEGALITE modular formwork is a modular wall and column formwork in imperial sizes. Is perfect for any vertical concrete structure in building construction (walls, columns, pilasters, wall intersections, foundations…). It allows manual erection or with crane handling.

Features

Permissible concrete pressure:

Walls up to 8’: Hydrostatic pressure (does not require speed control during concrete pouring)
Walls higher than 8’: Uniform pressure of 1250 psf

2 rows of tie rods in height up to 8’
Height range of panels: 8’, 6’, 5’ and 4’
8’x8’ and 8’x4’ panels: for sale only
Columns with universal panel

Column solution with panels of 6’’x 6’’ to 36’’x 36’’, adjustment interval every 2’’
Wider columns are possible by joining panels longitudinally
Concrete pressure: 1650 psf

Advantages

Light panels for easy handling
Lifting hook for the assembly of gangs and formwork lifting
Long-lasting resistant steel frames with reinforced corners
Quick and easy connection with MEGALITE Clamp
Versatile. All kind of solutions combining in perpendicular connection wall panels with lateral holes and universal panel with multipunched ribs
